12 Lead BT ECG (telehealth option)

Fast, accurate 12-lead ECG waveform data capture for easy integration to telehealth solutions.

The Vitalograph BT12 ECG combined with your mobile phone, tablet, or PC is a powerful electrocardiograph.

  • With its lightweight compact design it is ideal as both a stationary and portable ECG device.
  • Stream live ECG data via Bluetooth to your telehealth solution.
  • Compatible with apps on devices operating Android™ and Windows® via Bluetooth® connectivity.
  • Transmission of the ECG trace is wireless with no leads to trip over, providing excellent signal quality, less artifact and ensuring minimal patient discomfort.
  • API software developers’ kit is available to providers of telehealth solutions for ease of integration.


BT12 ECG comes with:

  • 12-Lead Resting ECG Measuring Unit
  • Electrode Cables
  • Batteries
  • Bluetooth Dongle


Comes with 5-Year Warranty with unlimited technical support if registered within 30-days of purchase.  If the instrument has been returned for annual service and calibration each year within one month of its purchase anniversary date, any repair parts required will then be warrantied for five years from the original date of purchase. A nominal fee plus shipping is charged for this optional annual service. The device must be registered within 30-days of purchase.

The Bluetooth® word, mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Vitalograph is under license.


Product Code: 41303_TH

  • Stream live ECG data via Bluetooth to your telehealth solution.
  • Instant visual feedback with the built-in display indicating heart rate, electrode contact problems, battery status and communication status.
  • Automatic pacemaker detection.
  • Automatic calculation of heart rate with acoustic and visual signal to aid assessment.
  • Bluetooth serial transmission protocol with a 10 meter range.
  • Runs on 2 x AA batteries offering portability and reduced artifacts from electrical power sources.
  • FDA Cleared & CE marked.
  • Can be comfortably worn on the subject’s body using the integrated fastening clip.
Model Number 4130
Dimensions W x H x D 6.1cm x 10.6cm x 2.3cm
Weight, incl. cable 210 g incl. batteries (154 g without batteries)
Power supply 2 * AA batteries (1.5 V) or rechargeable batteries (1.2 V)n
Data transmission Wireless, standard Bluetooth 2.1
EMC Standards EN60601-1-2015
Electrodes Standard clip ECG electrodes
Signal output Missing signal / connection termination Electrode loss
Sample Rate 500Hz
Digital Resolution 2.6 μV
Bandwidth 0.05 HZ – 150 Hz digital

Product Specification


No, the SDK provides details of the API which will enable integration developers to create their own telehealth applications. The BT12 streams live ECG waveform data via Bluetooth along with the heart rate and pacemaker detection data. It is the responsibility of the developers to display and calculate other measurements and interpretation based on the provided waveform data.
